1)Base roller: 45# steel tube or No5 series aluminum
2)Surface coating: Chrome oxide ceramic layer
Screen count range(LPI): 80-2000 LPI
Surface hardness: 1250HV-1350HV
Engraving angle( Screen angle): 1-89 degree
Cell shape : 30°honeycomb, 60°honeycomb(hexagon), 45°diamond(quadrangle,ART pattern ),curved flow(Cobra pattern), slanted(line pattern)or according to your actual requirement.
Step1:Based roller Processing
Step3:Nickel-Chromium Alloy Coating
Step4:Chromium Oxide Ceramic Layer
Step8:Polishing and Cleaning
1).Uniform cell shape,fast and even ink release;
We have the quality control system during the whole production from the very beginning to the end to make sure each roller is qualified. And we will issue the certification for our customers after the products finished .
2).Easy cleaning,ideal cell shape with smooth,steep walls and flat bottom;
We use the famous plasma spraying machine from Switzerland supplier to do the coating spray. The evenness of 80% ceramic powder can be controlled between 15u-35u and the hardness of chrome oxide ceramics can reach 1200HV.
3).Precise cell volume;
We make trial engraving before the real engraving.We use the scanner to scan each each layer to test the volume of cell then according to the relationship between the LPI and BCM to make sure the LPI we would like to reach.
4).Good corrosion resistance;
we use the nanoscopic sealant to coat on the surface of the ceramic which can reach the tiny cell to protect the base roller from solvent corrosion.
5).High bond strength with base metal.
6).Longer life expectancy;
Under nomal operation and maintenance,our ceramic anilox rollers can work 8-10years or even longer.
